PCIe 3.0 x4 Single-port RJ45 10G Ethernet Network adapter v2 (Aquantia AQtion AQC107)
LREC6880BT is a PCI Express 3.0 x4 single-port 10 Gigabit Ethernet network adapter independently developed by Linkreal Co., Ltd. based on the Aquantia AQtion AQC107 chip solution.
【Aquantia AQtion controller】: The 10g single-port RJ45 network card is based on the original Aquantia AQtion AQC107 controller, which provide power and space-efficient connectivity to client systems. PCIe 2.1 x4, compatible with x8 , x16.
【Supported operating systems】: Windows 7/8/8.1/10, Windows Windows Server 2008 R2 /2012 R2 /2016 R2 /2019 R2, Linux, Linux CentOS/RHEL 6.5 / 7.x or later, Ubuntu 14.x/15.x/16.x or later, etc.
【Technical Support】: WoL, Jumbo Frames, DPDK, PXE
【Easy to install】: install the operating system with its driver CD, or download it from the Intel official website. Includes low-profile and full-height stands to support standard and ultra-thin computers/servers.
【After Sales Service】: 24/7 customer service, 30-day free returns, 1-year free warranty, and lifetime technical support.
Jumbo Frame Transfer, No Frame Loss: PCIe x4 Single-port 10G Copper Ethernet Network Adapter LRES2051PT
Complete technical details for integration and deployment planning.
| Baffle Height | Low Profile & Full Height |
|---|---|
| Power Consumption | 4.75W |
| OS Support | Windows 7/ 8/ 8.1/ 10/ 11 |
| Bus Type | PCIe v3.0 x4 , compatible with x8 / x16 |
|---|---|
| Data rate per port | 10G/5G/2.5G/1G/100M |
| Connector | 1*10G RJ45 |
| Power Supply | PCIe |
| Standards compliant | IEEE 802.3an 10 Gbit/s Ethernet over unshielded twisted pairIEEE 802.3bz 2.5/5GBASE-TIEEE 802.3ab 1000BASE-T Gigabit EthernetIEEE 802.3u 100BASE-TX Fast EthernetIEEE 802.1Q VLANsIEEE 802.3x Full Duplex and flow controIEEE 802.3az - Energy Efficient Ethernet (EEE) |
| PXE | Yes |
| iSCSI | No |
| WoL | Yes |
| Jumbo Frames | Yes |
| DPDK | Yes |
| FCoE | No |
| Operating Temperature | 0℃ to 55℃ (32℉ to 131℉) |
| Storage Temperature | -40℃ to 70℃ (-40℉ to 158℉) |
| Storage Humidity | Maximum: 90% non-condensing relative humidity at 35℃ |
| Certification | FCC, RoHS, CE |
| PCB Size (mm ±0.5mm) | 105.1*68.1*1.6 （±0.1） |
| Size (mm ±0.5mm) | 179*150*30 （±0.1） |
| 2U Baffle | *1 |
| Installation guide | *1 |
| Product warranty card | *1 |
| Net Weigh (g) | * |
| The states | 10G , Orange Link + Green Blink |
