PCIe x1 Single-port Gigabit Desktop Copper Port Network Card (BCM5751)
LREC9210MT is PCI Express x1 Gigabit Ethernet desktop network adapter based on BCM5751 solution. The Gigabit adapter adopts a compact design and does not reduce the performance of the NIC.
The adapter adopts Ethernet power management technologies such as Energy Efficient Ethernet and DMA Merge, and has 4 transmit and 4 receive queues, error correction memory protection and other technologies to improve the reliability of data transmission. Manage latency data packets efficiently by combining parallel and pipe-lined logical architectures.
The adapter has high-performance network data transmission on the machine bus architecture, compatible with Ethernet and fast Ethernet to greatly reduce customer deployment and training costs.
Jumbo Frame Transfer, No Frame Loss: LR-LINK PCIe x4 Single-port 10G Copper Ethernet Network Adapter LRES2051PT
Complete technical details for integration and deployment planning.
| Jumbo Frame Support | Up to 9.5 KB |
|---|---|
| Operating Temperature | 0 °C to 55 °C (32 °F to 131 °F) |
| Network Virtualization | PXE |
| LED Indicators | 1000Mbps/s:Yellow Link and Green Ack, |
| Operating System Support | Windows Server2008 / 2008 R2 / 2012 /2012 R2 /2016 R2 |
|---|
