Intel E610 based dual-port 10G copper NIC with PCIe 4.0 x4 interface for data centers and edge IoT.
LR-LINK presents the LRES1060PT-2RJ45, a robust dual-port 10 Gigabit Ethernet network adapter designed for modern infrastructure needs. Built on the reliable Intel E610 chipset, this adapter delivers exceptional performance through a PCIe 4.0 x4 host interface, ensuring efficient data throughput for demanding workloads.
This network card supports auto-negotiation across multiple speeds (100M/1G/2.5G/5G/10G) over standard RJ45 copper interfaces, making it versatile for various cabling environments including Cat5e, Cat6, and Cat6a. It integrates essential enterprise features such as PXE/UEFI boot, Wake-on-LAN (WOL), Single Root I/O Virtualization (SR-IOV), and IEEE 1588 Precision Time Protocol (PTP) for synchronized operations.
Designed with efficiency in mind, the LRES1060PT-2RJ45 offers low power consumption while maintaining high security and stability. It is an ideal solution for data centers, network equipment, embedded systems, and edge IoT applications where balanced deployment flexibility and operational simplicity are critical.
Supports up to 10Gbps over dual RJ45 ports with auto-sensing capabilities.
Powered by Intel E610 controller for stable and secure data transmission.
Features SR-IOV support for enhanced virtual machine performance and isolation.
Optimized energy efficiency with max power consumption of only 4.08W.
Integrates IEEE 1588 PTP for precise time synchronization in industrial apps.
Complete technical details for integration and deployment planning.
| Host Interface | PCIe 4.0 x4 |
|---|---|
| Port Configuration | Dual-port |
| Connector Type | RJ45 |
| Link Speed | 100M/1G/2.5G/5G/10G |
| Cable Medium | Copper |
| Controller | Intel E610 |
|---|---|
| Power Consumption | Max 4.08W |
| Jumbo Frames | 9.7KB |
| Ethernet Standards | |
|---|---|
| Network Protocols | |
| Physical Layer |
| SR-IOV | YES |
|---|---|
| Wake-on-LAN (WoL) | YES |
| PXE/UEFI Boot | YES |
| 1588 PTP | YES |
| PCB Size | 125*68.9mm |
|---|---|
| Package Size | 222*147*28mm |
| LED Indicators | Link, Link Speed, Activity |
| Operating Temperature | -10°C to 60°C |
|---|---|
| Storage Temperature | -40°C to 70°C |
| Storage Humidity | Maximum: 90% non-condensing at 35°C |
| Compliance |
|---|
