PCIe x1 Single-port 2.5G Copper Ethernet Network Adapter (Intel I225)
LRES2031PT is a PCIe x1 single port 2.5G Ethernet network adapter developed by Shenzhen Linkreal Co., Ltd. based on Intel master control scheme. This adapter provides better network performance than gigabit network for high quality network requirements such as home network, home storage, online games and other applications. Solve in do not need to link but the use of gigabit can not be satisfied with the occasion.
By using the card to add a 2.5G speed network link port on the computer, to achieve faster than gigabit network speed, better cost-effective network card; It can be widely used in household storage, industrial computer, embedded computer, single board computer, digital multimedia and other applications.
PCIe x1 Single-port 2.5G Copper Ethernet Network Adapter (RTL8125BG): LRES2022PT
Complete technical details for integration and deployment planning.
Controller | Intel Chip | |
Baffle Height | Full-height & half-height bracket | |
Power Consumption | 2.0W | |
System Support | Windows 10 | |
* AMD is not support | ||
Bus Type | PCIe v3.1 x1，compatible with x4/x8/x16 | |
Data rate per port | 100MbE/1/2.5GbE | |
Connector | 1*2.5G RJ45 | |
Protocol Support | IEEE 802.3bz 2.5GBASE-T Ethernet IEEE 802.3ab 1000BASE-T Ethernet IEEE 802.3u 100BASE-TX Ethernet IEEE 802.3az - Energy Efficient Ethernet (EEE) IEEE 802.3z IEEE 802.1Q VLANs IEEE 802.3x IEEE 1588 | |
iSCSI | No | |
WoL | Yes | |
Jumbo Frames | YES | |
DPDK | Yes | |
PXE | Yes | |
FCoE | No | |
Latest certified drivers for all supported operating systems, ensuring optimal performance and compatibility.
Look up product firmware versions, hardware revisions, and OS compatibility by entering your part number or hardware version.
