Quad-port Gigabit Ethernet PCIe adapter based on Broadcom BCM5719 for server virtualization and high throughput.
LR-LINK presents the LRES2044PT, a robust quad-port Gigabit Ethernet network adapter built on the reliable Broadcom BCM5719 controller. Designed specifically for server environments, this PCIe v2.0 x4 card provides four independent 10/100/1000Mbps RJ45 ports, ensuring high port density and consistent performance for data-intensive tasks.
This adapter is ideal for virtualization, security, and server consolidation scenarios where high throughput and low latency are critical. It supports advanced hardware offloads such as TCP checksum, VLAN tagging, and Jumbo frames, which significantly reduce CPU overhead and optimize host efficiency for consolidated workloads.
The LRES2044PT ensures broad compatibility with industry-standard operating systems, including various versions of Windows Server, Linux distributions (CentOS, RHEL, Ubuntu), and VMware ESXi. With support for PXE boot and IEEE 1588 precision time protocol, it serves as a versatile solution for enterprise networking, network segmentation, and general server infrastructure needs.
Four independent Gigabit ports provide high port density for server consolidation.
Powered by Broadcom BCM5719 for stable and efficient network performance.
Supports VMware NetQueue and Microsoft VMQ for optimized virtual workloads.
Hardware offloads for TCP/IP and VLAN reduce CPU usage and increase throughput.
Compatible with major Windows, Linux, and VMware server operating systems.
Complete technical details for integration and deployment planning.
| Bus Type | PCIe v2.0 x4 |
|---|---|
| Data Rate | 10/100/1000 Mbps |
| Connector | 4x 8-Pin RJ45 |
| Port Configuration | Quad-port |
| Controller | Broadcom BCM5719 |
|---|
| Protocol Support | |
|---|---|
| Advanced Features |
| Size (mm) | 114 x 120 x 21 |
|---|---|
| Baffle Height | Half-height and Full-height configuration |
| LED Indicators | Link/Speed indicators (Green/Yellow) |
| Operating Temperature | 0°C to 55°C |
|---|---|
| Storage Temperature | -40°C to 70°C |
| Storage Humidity | Max 90% non-condensing at 35°C |
| Windows | 7/8/8.1/10/11; Server 2008R2-2022 |
|---|---|
| Linux | Kernel 2.6.x+; CentOS/RHEL/Ubuntu |
| Virtualization | VMware ESX/ESXi 4.x+ |
Look up product firmware versions, hardware revisions, and OS compatibility by entering your part number or hardware version.
