Quad-port 10G copper NIC based on Xilinx FPGA for cloud and industrial use.
LR-LINK presents the LREG1007PT, a specialized 10G intelligent network adapter built on an independent Xilinx FPGA solution. This card integrates four 10Gigabit Ethernet MACs with RJ45 connectors, providing comprehensive Layer 2 functionality including MAC and PHY layer management. It is engineered to effectively handle complex network traffic while maintaining low latency.
Designed for demanding applications such as cloud computing, network security, and industrial automation, this adapter offers kernel-mode and user-mode drivers compatible with Windows and Linux systems. Key features include support for DPDK high-performance packet processing, SR-IOV hardware virtualization, and multi-queue offloading, which significantly reduce CPU utilization during heavy data transfers.
The LREG1007PT delivers a total bandwidth capacity of 40Gbps across its four ports, supporting both 1G and 10G speeds over standard copper cabling (10GBase-T & 1000Base-T). With its robust feature set including Jumbo Frames up to 9.6KB and VLAN forwarding, it serves as an ideal solution for businesses seeking high-performance networking, accelerated processing, and reliable big data computing capabilities.
Delivers 40Gbps total bandwidth with Xilinx FPGA for efficient data processing.
Features four 10G RJ45 ports for versatile copper connectivity options.
Supports SR-IOV and multi-queue offloading to enhance virtualized environments.
Optimized for DPDK high-performance packet receiving and sending tasks.
Robust design suitable for cloud, security, and industrial control scenarios.
Complete technical details for integration and deployment planning.
| Port Configuration | Quad-port |
|---|---|
| Connector Type | 4x RJ45 |
| Data Rate per Port | 1G/10Gbps |
| Cable Medium | Copper |
| Cable Type | 10GBase-T & 1000Base-T |
| Controller | Xilinx FPGA |
|---|---|
| Total Bandwidth | 40Gbps |
| Bus Interface | PCIe 3.0 x8 |
| DPDK Support | Yes |
| SR-IOV Support | Yes |
| Bracket Height | Low Profile & Full Height |
|---|---|
| PCB Size | 164*68.9*1.6 mm |
| Power Consumption (Min) | 18.42W |
| Power Consumption (Max) | 33W |
| Power Supply | PCIe |
| Operating Temperature | 0℃ to 55℃ |
|---|---|
| Storage Temperature | -40℃ to 85℃ |
| Storage Humidity | Max 90% non-condensing at 35℃ |
| ESD Contact Discharge | ±6KV |
| Lightning Surge | ±1KV (common-mode) |
| Compliance | FCC, CE, RoHS |
|---|
