40G Single-Mode QSFP+ 10km Fiber Optical Transceiver
LR-LINK LRFQ1340-X10ATM is a high performance, low power consumption, long reach interconnect solution supporting 40G Ethernet, fiber channel and PCIe. It is compliant with the QSFP MSA and IEEE 802.3ae 10GBASE-LR/LW3. QSFP PSM LR4 is an assembly of 4 full-duplex lanes, where each lane is capable of transmitting data at rates up to 10.3125Gb/s, providing an aggregated rate of 40Gb/s.
Complete technical details for integration and deployment planning.
| Parameter | Symbol |
|---|---|
| Supply Voltage | Vcc |
| Input Voltage | Vin |
| Storage Temperature | Ts |
| Case Operating Temperature | Tc |
| Humidity(non_condensing) | Rh |
| Parameter | Symbol |
|---|---|
| Supply Voltage | Vcc |
| Operating Case Temperature | Tc |
| Data Rate Per Lane | fd |
| Humidity | Rh |
| Power Dissipation | Pm |
| Fiber Bend Radius | Rb |
| Parameter | Symbol |
|---|---|
| Lane Wavelength Range | λc |
| SMSR | σ |
| Average Launch Power (each lane) | Pout |
| Optical Modulation Amplitude (each lane) | OMA |
| Transmitter and dispersion penalty (TDP), each lane | TDP |
| Extinction Ratio | ER |
| Average Launch Power of OFF Transmitter (each lane) | Poff |
| Parameter | Symbol |
|---|---|
| Lane Wavelength Range | λc |
| Receiver sensitivity in OMA, each lane | - |
| Stressed Receiver Sensitivity in OMA | - |
| Average Power at Receiver | - |
| Receiver Reflectance | RR |
| LOS Assert | LOSA |
| LOS De-Assert | LOSD |
| LOS Hysteresis | LOSH |
| Parameter | Symbol |
| Differential Input Impedance | Zin |
| Differential Output Impedance | Zout |
| Differential Input Voltage Amplitude1 | ΔVin |
| Differential Output Voltage Amplitude2 | ΔVout |
| Skew | Sw |
| Bit Error Rate | BER |
| Input Logic Level High | VIH |
| Input Logic Level Low | VIL |
| Output Logic Level High | VOH |
| Output Logic Level Low | VOL |
